E-3
MONITOR COMPONENTS
Display
MEMORY Button
START Button
(Orange illumination during the AM)
(Blue illumination during the PM)
Air Socket
AM Button
PM Button
Air Connector Plug
Air Hose
Arm Cuff
AC Adapter Jack
AC Adapter
Battery Compartment
Battery Cover
FRONT
BACK
