LifeSpan RHYTHM - Parts List

25
RHYTHM
11. PARTS LIST
#
DESCRIPTION
REMARK
QTY
#
DESCRIPTION
REMARK
QTY
1
Main Frame
1
53
Bolt
M8*12
8
2
Base frame
1
54
Bolt
M8*30 L15
4
3
Right upright tube
1
55
Flat Washer
8
6
4
Left upright tube
1
56
Spring Washer
8
6
5
Console Bracket
1
57
Bolt
M8*25 L20
1
6
Incline Bracket
1
58
Bolt
M8*42 L20
1
7
Right Speaker Cover
1
59
Bolt
M10*20
2
8
Left Speaker Cover
1
60
Bolt
M10*45
2
9
Console
1
61
Bolt
M10*60 L35
4
10
Cylinder
1
62
Bolt
M6*35
8
11
Casing
2
63
Screw
ST4.2*19
4
12
Front Roller
1
64
Screw
ST2.9*9.5
2
13
Back Roller
1
65
Screw
ST4.2*12
13
14
Left Back End Cover
1
66
Screw
ST4.2*28
2
15
Right Back End Cover
1
67
Screw
ST4.2*12
7
16
Motor Up Cover
1
68
Lock Washer
5
3
17
Motor Bottom Cover
1
69
Bolt
M6*10
2
18
Running belt
1
70
Running Board
1
19
Foot Pad
4
71
DC Motor
1
20
Roller Cover
2
72
Incline Motor
1
21
Basic Left Cover
1
73
Bottom Control Board
1
22
Basic Right Cover
1
74
Pulse device with speed button
1
23
Washer
Φ8*24*2
1
75
Pulse device with incline button
1
24
Console Up Cover
1
76
Computer up wire
1
25
Left Side Rail
1
77
Computer down wire
1
26
Right Side Rail
1
78
Light Sensor
1
27
Left Back End Cover
1
79
Safety lock
1
28
Right Back End Cover
1
80
Switch
1
29
Adjust wheel
2
81
Standard power cord
1
30
Tapered Cushion
2
82
Overload protection
1
31
Bottom Cover Plate
1
83
Power line deduction
1
32
Ring wire plug
1
84
AC single wire
1
33
Transport Wheel
2
85
Magnetic Ring
1
34
Round End Cap
2
86
Blue Single Wire
1
35
Motor Belt
1
87
Brown Single Wire
1
36
Foam Grip
2
88
6# Allen Wrench
6mm
1
37
Strengthen Rod Assembly
1
89
Wrench Screw Driver
S=13、14、15
1
38
Bolt
M8*40
4
90
5# Allen Wrench
5mm
1
39
Lock Washer
8
15
40
I shape Lock Nut
M8
8
92
Rubber Pad
Black
4
41
I shape Lock Nut
M10
2
93
EVA Cushion
1
42
Bolt
M10*42
1
94
Transformer
1
43
Bolt
M10*55
1
95
Rubber foot pad
4
44
Lock Washer
10
12
96
Washer
2
45
Nut
2
97
Washer
6
6
46
Bolt
M8*25
2
98
Screw
ST4.2*30
3
47
Console Bottom Cover
1
99
Bolt
M8*50 L20
4
48
Bolt
M6*16
4
100
Rubber foot pad
Red
4
49
Incline frame shaft
2
101
Screw
ST4.2*20
6
