LifeSpan RHYTHM - Page 8

8
RHYTHM
STEP 4:
STEP 5:
1. Using the 5# Allen Wrench, lock the Right
Upright Tube (3) onto the base frame with
Bolt (61) M10*60, Lock Washer (40) and
lock nut.
2. Use the 5# Allen Wrench to lock the Left
Upright Tube (4) onto the base from with
Bolt (53) and Lock Washer (39)
3. Assemble the Left Upright Tube onto the
base frame following the same
procedures as the Right Upright Tube
1. Use Allen Wrench, and bolt ST4.2*19 (63) to
lock the Base Right Cover to the right upright
tube
2. Assemble the Left Upright Tube onto the
base frame following the same procedures as
the Right Upright Tube
