5
TOOL CORRAL INSTALLATION HARDWARE [AYL]
Hardware shown at actual size
Part shown at 15% of actual size
ADZ (x2)
1/4" x 5/8" Phillips Pan-Head Screw
ADX (x8)
#10 x 1/2" Phillips Pan-Head Screw
PARTS & HARDWARE LIST
HARDWARE IDENTIFIER
ID Description Quantity
Main Part
AYG Tool Corral 1
AYL Tool Corral Installation Hardware
ADZ 1/4” x 5/8” Phillips Pan-Head Screw 2
ADX #10 x 1/2” Phillips Pan-Head Screw 8
PARTS IDENTIFIER
AYG (x1)
Tool Corral
Note: Throughout the Parts & Hardware List, Part & Hardware Identifiers, and instructions are three-
letter IDs. These IDs are below the images of the parts and hardware to help you locate and identify
the parts and hardware during assembly. These IDs are not necessarily on the parts themselves.
!
