Lifetime 60030 - Step 1.7: Attach Bench Assembly; Step 1.8: Secure Second Bench Assembly

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
9
SEC
1
BWI (x6)
SEC
1.7
Place a Bench Assembly (BWN) underneath one of the Legs and slide the Sliding End Caps under the glide rails of
the Bench Assembly as shown.
Glide Rail
SEC
1.3
Attach two (2) Sliding End Caps (BWI) to the tube on the other Table Leg, and lift the Bench Assembly upward until
the Sliding End Caps rest inside the underside of the Bench. Position the Bench so all four Sliding End Caps are
under the glide rails. Repeat steps 1.6 - 1.8 for the second Bench Assembly.
SEC
1.8
BWN
2 ADULTS REQUIRED FOR THESE STEPS
