10
4.1: Snap a Wall Panel (108) into place along shorter side of shed.
Look to make sure holes line up and then fasten panels together with
Screws (SS).
4
Do Not Over-Tighten Screws
4.2: Fold Left Back Corner Panel (107). Snap into place and fasten with Screws (SS).
SS (10)
107
Place Wood Block (BD) directly under
the tab you are inserting. Snap tabs
into place one at a time.
A second person should
apply pressure on
opposite side of the wall
for easy insertion of screws.
Assemble Left Wall
Hardware Bag:
1001634
Drill/Screwdriver
108
To Next Page
