TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
12
SEC
NO HARDWARE REQUIRED FOR THIS PAGE
2
Remove this panel whether it’s a regular Wall
Panel or Window Wall Panel.
Remove this panel whether it’s a regular
Wall Panel or Window Wall Panel.
SEC
2.1
Remove the four Center Roof Panels and two Center Roof Caps highlighted below.
SHED DISASSEMBLY
SEC
2.2
Remove all Screws from the highlighted Wall Panel that connect it to adjoining Wall Panels and to the Wall Support.
**SAVE ALL HARDWARE FOR RE-ASSEMBLY!**
If your existing shed is anchored to the ground, remove all anchoring hardware before following these
steps.
Note: Your shed may be shorter than one shown above. Skip the very back Roof Panels (slightly more narrow than the middle Roof Panels) and
then remove the next two Roof Panels from each side of the shed (along with the connected Roof Caps).
!
