Lifetime 90029 - SEC 3 Tetherball to Pole Assembly

14
ABD (x1)
5/16” Flat Washer
BUF (x1)
Washer Collar Link
AYT (x1)
5/16” Hex Nut
TETHERBALL TO POLE ASSEMBLY
HARDWARE REQUIRED
PARTS REQUIRED
TOOLS USED (NOT INCLUDED)
SEC
3
Hardware shown at actual size
Safety Glasses
*AZT (x1)
Ball/Rope/Clasp Assembly
AZQ (x1)
2” Expanding Pole Cap
AZR (x1)
2” Pole Cap Wedge
Part not shown to scale
EQX (x1)
5/16”-18 x 3” Hex Bolt
BCA (x1)
Top Cap
