Lifetime 90029 - Page 15

TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
15
SEC
3
Connect the Top Cap (BCA), Washer Collar Link (BUF), Expanding Pole Cap (AZQ), and Pole Cap Wedge (AZR) together using the hardware
shown. Hand tighten the Nut (AYT) just enough to secure it inside the Pole Cap Wedge.
SEC
3.1
ABD (x1)
BUF (x1)
AYT (x1)
TETHERBALL TO POLE ASSEMBLY
EQX
ABD
BCA
BUF
AZQ
AZR
AYT
EQX (x1)
