10
TOOLS AND HARDWARE REQUIRED / OUTILS ET QUINCAILLERIE REQUIS / HERRAMIENTAS Y HERRAJE REQUERIDOS
X SECTION 1 (CONTINUED) / SECTION 1 (SUITE) / SECCIÓN 1 (CONTINUACIÓN)
• Secure the poles together with self-drilling screws (ABZ).
• Attachez les poteaux les uns aux autres à l’aide des vis autotaraudeuses (ABZ).
• Sujete los postes el uno al otro con tornillos autoroscantes (ABZ).
1.6
ABZ
ALH
ALF
ALE
ABZ
ABZ (x2)
• For ease of installation, chuck the self-drilling screws
directly into the drill, or use a 3/8” hex driver.
• Pour faciliter l’installation, mettez les Vis autotaraudeuses
directlement dans la Perceuse, ou utilisez un tournevis à
écrou de 3/8 po.
• Para facilitar la instalación, fi je los Tornillos autoroscantes
directamente en el taladro, o use una llave de tuerca de
3/8 in/po.
!
(x1)
