22
TOOLS AND HARDWARE REQUIRED
X SECTION 2 (CONTINUED)
2.7
2.8
AWS (x2)
ATG (x4)ASB (x2)
CVZ (x2)
CQA
CQA
AWS
AWS
ASB
ASB
CVZ
CVZ
ATG
ATG
ATG
ATG
2
3
4
1
!
• Place the hardware in the order shown.
• Only fi nger-tighten this
hardware.
.
!
• Position the Cockpit Seat Support (CQA) in the location shown, with a Coped Cap (AWS) on each end. Place the
hardware through the Fuselage frames and into the seat support and fi nger tighten. This hardware will be removed
and reused later in the assembly.
• Place the Cockpit Seat (CPZ) in the position shown. Tip the fuselage on its side to secure the Cockpit Seat with the
hardware depicted in the order shown.
3/16 in/po (≈5 mm)
(2)
