23
TOOLS AND HARDWARE REQUIRED
X SECTION 2 (CONTINUED)
AWS (x2)
ASB (x2)
ATG (x4)
CVZ (x2)
CQA
AWS
AWS
ASB
ASB
CVZ
CVZ
CQA
ATG
ATG
ATG
ATG
1
2
3
4
!
• Place the hardware in the order
shown.
• Only fi nger-tighten this hardware.
• Ne serrez les accessoires que pour la main.
• Apriete los accessorios sólo a mano.
!
• Position the Cockpit Seat Support (CQA) in the location shown, with Coped Caps (AWS) on each end of the tube. Place
the hardware through the fuselage frames and into the seat support and fi nger tighten as shown. This hardware
will be removed and reused later in the assembly.
• Place the Cockpit Seat (CPZ) in the position shown. Tip the fuselage on its side to secure the Cockpit Seat with the
hardware depicted in the order shown.
2.9
2.10
3/16 in/po (≈5 mm)
(2)
To Next Page
