TOOLS AND HARDWARE REQUIRED
X SECTION 1 (CONTINUED)
5
1.4
AOU
ABK
9/16" (14 mm)
• Insert the U-Bolt (AOU) through the upper holes on the backside of the Backboard (not included). Secure the Rim and
Plastic Guard (ALD) to the Backboard with the Flange Nuts (ABK) provided.
Backboard not included
ABK (x2)
AOU (x1)
!
• THIS STEP MAY NEED TO BE PERFORMED
DIFFERENTLY!
When attaching the Rim to a Backboard,
you will first need to attach the U-Bolt to
the proper mounting equipment. See the
assembly instructions included with your
Basketball System or Mounting Kit before
completing this step.
Rim Support Channel
(not included)
ALD
To Next Page
