Lightmaxx LIG0009566-000 User Manual

15
DMX Protocol:
13channel mode:
Channel
Name
DMX
VALUE
1
PAN
0-255
Pan Movement By 540/360
2
TILT
0-255
Tilt Movement By 270
3
PAN/TILT SPEED
0-255
Pan/tilt moving speed with decreasing
4
Colour Wheel
0-13
White
14-27
Yellow
28-41
Rose Pink
42-55
Green
56-69
Pink Carnation
70-83
Blue
84-97
Spring Yellow
98-111
Deep Straw
112-127
Pink
128-191
Forwards rainbow effect with increasing speed
192-255
Backwards rainbow effect with increasing speed
5
Gobo Wheel
0-9
Open
10-19
gobo 1
20-29
gobo 2
30-39
gobo 3
40-49
gobo 4
50-59
gobo 5
60-69
gobo 6
70-79
gobo 7
80-99
gobo 1 shake from slow to fast
100-119
gobo 2 shake, from slow to fast
120-139
gobo 3 shake, from slow to fast
140-159
gobo 4 shake, from slow to fast
160-179
gobo 5 shake, from slow to fast
180-199
gobo 6 shake, from slow to fast
200-219
gobo 7 shake, from slow to fast
220-255
gobo wheel rotation with increasing speed
6
Bobo Rotation
0-127
No rotation
128-191
forwards gobo rotation with increasing
speed
192-255
Backwards gobo rotation with increasing
speed
7
Shutter
0-9
closed
10-19
open
20-127
Strobe effect 1 with increasing speed
128-137
open
138-201
strobe effect 2 with increasing speed
202-255
open
8
Dimmer
0-255
Intensity 0 to 100%
9
Focus
0-255
Continuous adjustment from far to near
10
Prism
0-3
open
4-127
close
128-255
Rotation from fast to slow

Lightmaxx LIG0009566-000 Specifications

Power

power supply	230 V/50 Hz
power consumption	100W
led power	60W white LED
fuse	F2A, 250V

Movement

pan movement	within 540°
tilt movement	within 270°

Lighting and Effects

number of colours	8 dichroic + white
number of gobos	7 gobos + open

Control

dmx-control-channels	13CH & 8CH
dmx-512-connection	3-pin XLR
sound-control	via built-in microphone

Weight and Dimensions

packing size	275 x 225 x 400mm
net weight	9.0 kg
