Lightmaxx LIG0009566-000 User Manual

17
4
Gobo Wheel
0-9
Open
10-19
gobo 1
20-29
gobo 2
30-39
gobo 3
40-49
gobo 4
50-59
gobo 5
60-69
gobo 6
70-79
gobo 7
80-99
gobo 1 shake from slow to fast
100-119
gobo 2 shake, from slow to fast
120-139
gobo 3 shake, from slow to fast
140-159
gobo 4 shake, from slow to fast
160-179
gobo 5 shake, from slow to fast
180-199
gobo 6 shake, from slow to fast
200-219
gobo 7 shake, from slow to fast
220-255
gobo wheel rotation with increasing
speed
5
Bobo Rotation
0-127
No rotation
128-191
forwards gobo rotation with increasing
speed
192-255
Backwards gobo rotation with increasing
speed
6
Shutter
0-9
closed
10-19
open
20-127
Strobe effect 1 with increasing speed
128-137
open
138-201
strobe effect 2 with increasing speed
202-255
open
7
Focus
0-255
Continuous adjustment from far to near
8
Prism
0-3
open
4-127
close
128-255
Rotation from fast to slow
CLEANING AND MAINTENANCE
The operator has to make sure that safety-relating and machine-technical installations are inspected by an expert after
every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are inspected by a skilled
person once a year.
The following points have to be considered during the inspection:
1) All screws used for installing the devices or parts of the device have to be tightly connected and must not be
corroded.
2) There must not be any deformations on housings, fixations and installation spots (ceiling, suspension, trussing).
3) The electric power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any
safety problems have to be removed.

Lightmaxx LIG0009566-000 Specifications

Power

power supply	230 V/50 Hz
power consumption	100W
led power	60W white LED
fuse	F2A, 250V

Movement

pan movement	within 540°
tilt movement	within 270°

Lighting and Effects

number of colours	8 dichroic + white
number of gobos	7 gobos + open

Control

dmx-control-channels	13CH & 8CH
dmx-512-connection	3-pin XLR
sound-control	via built-in microphone

Weight and Dimensions

packing size	275 x 225 x 400mm
net weight	9.0 kg
