Connection with the mains
Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable
Pin
International
Brown
Live
L
Blue
Neutral
N
Yellow/Green
Earth
The earth has to be connected!
OPERATION
After you connected the effect to the mains, the
DMX LED MOVING SPOT starts running. During
the Reset, the motors are trimmed and the device
is ready for use within approximately 20 seconds.
Turn the objective-lens for adjusting the focus in
order to obtain a sharp projection.
LED display instructions:
ADDR
A001~AXXX
(AXXX)
DMX Address
SOUND
MAST (SO-M)
Sound active as MASTER
fixture
ALON (SO-A)
Sound active
independently
AUTO
MAST (AU-M)
Auto run as MASTER
fixture
ALON (AU-A)
Auto run independently
SHOU
SHO1
SHOW 1
SHO2
SHOW 2
RPAN
ON/OFF
Reverse pan
RTIL
ON/OFF
Reverse tilt
RDIS
ON/OFF
Display upside down
DEGR
540/360
Moving degree selection
CHMO
13CH/08CH
DMX channel mode
selection
MIC
M-XX
Sound sensitivity
FITI
0000-9999Hour
Fixture using time
REST
Reset
LOAD
Loading datas

Lightmaxx LIG0009566-000 Specifications

Power

power supply	230 V/50 Hz
power consumption	100W
led power	60W white LED
fuse	F2A, 250V

Movement

pan movement	within 540°
tilt movement	within 270°

Lighting and Effects

number of colours	8 dichroic + white
number of gobos	7 gobos + open

Control

dmx-control-channels	13CH & 8CH
dmx-512-connection	3-pin XLR
sound-control	via built-in microphone

Weight and Dimensions

packing size	275 x 225 x 400mm
net weight	9.0 kg
