Lightmaxx LIG0009566-000 User Manual

18
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use alcohol or solvents!
The interior of the device should be cleaned at least annually using a vacuum-cleaner or an air-jet.
There are no serviceable parts inside the device except for the lamp and the fuse. Maintenance and service
operations are only to be carried out by authorized dealers.
TECHNICAL SPECIFICATIONS
Power supply: 230 V/50 Hz
Power consumption: 100W
Led: 60W white LED
DMX-control-channels: 13CH & 8CH
DMX-512-connection: 3-pin XLR
Sound-control: via built-in microphone
Number of colours: 8 dichroic + white
Number of gobos: 7 gobos + open
PAN-movement: within 540°
TILT-movement: within 270°
Fuse: F2A, 250V.
Packing Size (LxWxH): 275 x 225 x 400mm
Net Weight: 9.0 kg
www.musicstore.com

Lightmaxx LIG0009566-000 Specifications

Power

power supply	230 V/50 Hz
power consumption	100W
led power	60W white LED
fuse	F2A, 250V

Movement

pan movement	within 540°
tilt movement	within 270°

Lighting and Effects

number of colours	8 dichroic + white
number of gobos	7 gobos + open

Control

dmx-control-channels	13CH & 8CH
dmx-512-connection	3-pin XLR
sound-control	via built-in microphone

Weight and Dimensions

packing size	275 x 225 x 400mm
net weight	9.0 kg
