Lightmaxx Shaft 5R User Manual

LightmaXX Shaft 5R Beam Moving Head ______
13
CH6 Prism Rotation
DMX Value
Effect
Attribute
193—255
191—192
128—190
0—127
Clockwise Rotation, Slow ->Fast
Stop
Anticlockwise ,Rotation, Fast->Slow
0°->540°
Linearity
Single-step
Linearity
Linearity
CH7 Prism Effect
Movement
DMX Value
Effect
Attribute
0—255
Near - wide
Linearity
CH8 Atomization
Frost Effect
DMX Value
Effect
Attribute
0—255
Atomization white ->full
Linearity
CH9 ZOOM
DMX Value
Effect
Attribute
0-255
ZOOM near->far
Linearity
Explanation ：CH10 Each unit adjust angle 2.12°
CH10 X axle PAN
movement
DMX value
Effect
Attribute
0—255
X axle movement 0°—540°
Linearity
Explanation ：CH11 Each unit adjust angle 0.008°
CH11 X axle PAN fine
adjustment
DMX Value
Effect
Attribute
0—255
X axle Micro rotation 0°—2.12°
Linearity
Explanation ：CH11 Each unit adjust angle 0.98°
CH12 Y axle TILT
Movement
DMX Value
Effect
Attribute
0—255
Y axle rotation 0°—540
Linearity
Explanation ：CH13 Each unit adjust angle 0.004°
CH13 Y axle fine TILT
adjustment
DMX value
Effect
Attribute
0—255
Y axle fine tuning 0°—0.98°
Linearity
CH 14 macro function
DMX value
Effect
Attribute
0-255
Unused
Attribute
CH15 Reset
DMX value
Effect
Attribute
128—255
77—127
26—76
0—25
The complete machine reset
XY axles reset
Effective parts reset （color 、Gobo 、Lens, etc. ）
Free
single step delay 5seconds
single step delay 5seconds
single step delay 5seconds
CH16 Bulb switch
DMX value
Effect
Attribute
101—255
26—100
0—25
Turn on
Turn off
Free
single step delay 5seconds
single step delay 5seconds
CH17 The speed of XY
axle
DMX value
Effect
Attribute
251-255
1-250
0
The Fastest
Speed Linear reduction
The Fastest
Linearity
Linearity
Linearity
