Connections and Control Elements:
1 Fixing Screw
2 COB LED-Lens
3 Power Cable
4 Fan Outlet
5 DMX Input (3-pole)
6 DMX Output (3-pole)
7 Display
8 Menu buttons
9 Safety
10 Microphone
Control Elements:
Start:
Connect the device to the power supply and wait a few seconds until it is ready
for operation.
Menu:
Navigation in the menu is performed using the four menu buttons below the display. Use the
„Menu“ key to activate the menu, navigation is done using the „Up“ and „Down“ keys.
A corresponding selection is confirmed with the „Enter“ key.
Operating Mode Auto or Sound:
The device contains automatic programs that run according to fixed schemes (auto)
or are called up via the built-in microphone to match the music (sound).
The selection of the respective mode is made via the menu
directly on the device.
Operating Mode Remote Control:
The unit can be remote controlled using the remote control
included in the delivery. The respective functions can be
performed using the various program selection or color keys.
1
2
3
4
5
6
7
8
9
10
