Lightmaxx VEGA PAR COB User Manual

19
DEUTSCH ENGLISH
The Menu in Detail:
Specifications:
Model Lightmaxx Vega PAR COB
LEDs 1x 30 Watt 1in1 COB LED
Colour Mix RGBWA
Dimmer 0-100%
Strobe
0-20Hz
LED Display Yes
Power Supply AC 100-240V/50-60HZ
Power Consumption 55W
Power Connection Fixed cable
Programs Auto, Sound, Static, DMX, Master/Slave
DMX Modi 9 Channels
Gewicht 1,75 Kg
MODE Program Description
A001~A511 A00~A511 DMX mode jump strobe: have already connected to DMX, display
SLAV: have already received master signals
Au**
Au 1~Au15 Fixed color, 1~31 represents 5 color LED mixed color
FF**
FF 1~FF99 Jump variable, the last two figure more big, the color change
speed will more fast
CC** CC 1~CC99 Gradual variable, the last two figure more big, the color change
speed will more fast
EE** EE 1~EE99 Pulse variable, the last two figure more big, the color change
speed will more fast
F*** F001~F009 No strobe
F010~F255 The last three figure more big, the strobe speed will more fast
AuTo AuTo Auto mode, Repeat play FF**, CC**, EE**, F***
Sound Sound Sound mode 1
bLOF/bLON Press ENTER button, „bL“ flicker, „OF“ means without sound acti-
vated but not shut off, „ON“ without sound activated black out
VOL1~VOL9 Press ENTER button, „VOL“ flicker, „1~9“ means sound sensitivity,
the value more bis, sensitivity more high
