Installation
NOTE: A standard handheld or other LightwaveRF remote control will only
be able to utilise the ‘on’ and ‘o’ commands to switch between circuits but
NOT use the stop command, as it does not include this function.
To operate the stop command you will need a LightwaveRF ‘On/O/Stop
Switch’ which includes ‘on/o’ (open/close) and ‘stop’ commands OR the
LightwaveRF App (requires Lightwave Link).
If you are using the App, you must slect the device as ‘open/close’ during
linking process (see in-app help). This will give you the ‘stop’ command as
well as on/o (open/close) when you come to operate the device from the
smartphone.
Curtains, Blinds and Doors
Because of the ‘stop’ command feature, the relay can be used to operate a
device that requires an on/o (or open/close) function AND a stop (or
pause) function, such as blinds, curtains and doors.
In this case, as before, the incoming live wire will be connected to the ‘com’
terminal, and there will be two separate outgoing ‘load’ wires each
connected to the separate switched live (or load) terminals (see diagram on
the next page).
