Lilliput A7S User Manual

4
2. DV BATTERY MOUNT PLATE
Standard mounts process
 First place battery plate into the slot, then slide the switch to left.
 Then slide the battery plate down into the slot.
Following two types of battery plates are suitable for this device, the standard
option of battery plate model is F970.
MODEL: F-970 MODEL: LP-E6
DV Battery Mount Plate Specification:
Model F970 for battery of SONY DV:
DCR-TRV series, DCR-TRV E series, VX2100E PD P series, GV-A700,
GV-D800 FD/CCD-SC/TR3/FX1E/HVR-AIC, HDR-FX1000E, HVR-Z1C,
HVR-V1C, FX7E F330.
Model LP-E6 for battery of Canon DSLR:
5D Mark II/5D Mark III/EOS6D/EOS7D/EOS60D/EOS70D；

Lilliput A7S Specifications

General

Screen Size	7 inches
Resolution	1920 x 1200
Aspect Ratio	16:10
Brightness	500 cd/m²
Contrast Ratio	1000:1
Inputs	HDMI
Power Consumption	12W
Input Voltage	7-24V
Viewing Angles	160°/160°
Weight	0.48 kg
