Lilliput A7S User Manual

6
Main Menu
Picture, Marker, Function, Waveform, Audio, System
Brightness
0~100
Contrast 0~100
Saturation 0~100
Tint 0~100
Sharpness 0~100
Color Temp 6500K, 7500K, 9300K, User (R.G. B)
Red Gain 0~255
Note: Available only under
“User” mode to choose the
color value you need.
Green Gain 0~255
Blue Gain 0~255
Red Offset 0~511
Green Offset 0~511
Blue Offset 0~511
Marker
Center Marker ON, OFF
Aspect Marker OFF, 16:9, 1.85:1, 2.35:1, 4:3, 3:2
Safety Marker OFF, 95%, 93%, 90%, 88%, 85%, 80%
Marker Color Red, Green, Blue, White, Black
Grid OFF, ON
Marker Mat OFF, 1, 2, 3, 4, 5, 6, 7
Thickness 2, 4, 6, 8
Function
Scan
Aspect, Pixel To Pixel, Zoom
Aspect Full, 16:9, 1.85:1, 2.35:1, 4:3, 3:2
Underscan OFF, ON
Check Field OFF, Mono, Red, Green, Blue
Zoom x1.5, x 2, x 3, x 4
Freeze OFF, ON
DSLR OFF, 5D2, 5D3
Waveform
Peaking OFF, ON
Peaking Color Red, Green, Blue, White, Black
Peaking Level 0~100
False Color OFF, ON
Exposure OFF, ON
Exposure Level 0~100
Histogram OFF, ON
Audio
Volume 0~100
Level Meter OFF, ON
System
Language English, Chinese
OSD Timer 10s. 20s, 30s
Image Flip OFF, H, V, H/V
Back Light 0~100
F1 Configuration
Peaking
F2 Configuration
Level Meter
Reset Press to confirm after selected.

Lilliput A7S Specifications

General

Screen Size	7 inches
Resolution	1920 x 1200
Aspect Ratio	16:10
Brightness	500 cd/m²
Contrast Ratio	1000:1
Inputs	HDMI
Power Consumption	12W
Input Voltage	7-24V
Viewing Angles	160°/160°
Weight	0.48 kg
