Resistance
Range Resolution Accuracy Overload
Protection
200Ω 0.1Ω
2kΩ 1Ω 600Vp
20kΩ 10Ω ±(0.8%+5)
200kΩ 100kΩ
2MΩ 1kΩ
20MΩ 10MΩ ±(1.5%+5)
Continuity test
Range Resolution Accuracy
1Ω 600Vp
Dwell test
Range Resolution Accuracy Overload
Protection
4CYL
6CYL 0.1° ± (3%+5) 600Vp
8CYL
Tach (Rotation Speed) test
Range Resolution Accuracy Overload
Protection
4CYL
6CYL 10 RPM ± (3%+5) 600Vp
8CYL
3
Tabels
