Overview
This Operating Manual covers information on safety and cautions.
Please read the relevant information carefully and observe all the
Warnings and Notes strictly.
Limit 500 Auto are 3 1/2 digits multimeter, especially designed for
automotive troubleshooting but also for all kind of electrical measur-
ing. The display have large digits and also shows correct test leads
terminals and rotary switch position, makes this instrument easy to
handle for the user.
General Specifications
Measuring range and accuracy see page 2-3.
• Fused
µ
mA Input terminal: 0,5A, 250V fast type, 5x20 mm
• Fused 10 A Input terminal: 10 A, 250V fast type, 5x20 mm
• Range: Manual ranging
• Maximum Display: Display: 1999 or
3 1/2
digits.
• Measurement Speed: Updates 2-3 times /second.
• Temperature: Operating: 0°C~40°C (32°F~104°F).
Storage: -10°C~50°C (14°F~122°F).
•
Battery Type: One piece of 9V Battery NEDA 1604 or 6F22 or 006P.
• Safety/Compliances: IEC61010 CAT II 1000V, CAT III 600 V
over voltage and double insulation standard.
• Certification:
Safety Information
This Meter complies with the standards IEC61010: in pollution
degree 2, over voltage category (CAT II 1000V, CAT III 600V) and
double insulation.
Warning
To avoid possible electric shock or personal injury, and to
avoid possible damage to the Meter or to the equipment under
6
500
Auto
