SMB/SB Installation and Maintenance Manual 140-11000 • July 2003
3
Actuator Weights
The approximate weights of the SMB actuators and SB and SBD options are provided below:
Table 3.1 – Actuator Weights
1
Actuator Weight
1
Adder for SB Adder for SBD
lb. kg lb. kg lb. kg
SMB-000 135 62 N/A N/A N/A N/A
SMB-00 200 90 65 30 100 46
SMB-0 350 159 180 83 210 97
SMB-1 460 209 200 92 325 150
SMB-2 580 263 220 101 345 159
SMB-3 1200 553 500 230 825 380
SMB-4&4T 2020 916 795 366 1285 591
SMB-5&5T 3375 1531 N/A N/A N/A N/A
SMB-5XT 5875 2665 N/A N/A N/A N/A
NOTE 1: With the largest motor, no integral controls, and standard compartment cover.
