Installation
Qualified personnel must carry out all installation work.
Work Surface Installation
The work surface onto which the appliance is to be sited must have the relevant physical
properties to sustain the working weight of the relevant appliance.
Working Weights
EB3 30.5kg
EB4 34.5kg
EB6 46kg
EB6T 46kg
If water, electrical and drainage services are to be brought through the work surface ensure there
is sufficient cable slack, movement for the flexible inlet hose and drain tubing (optional) to allow
for free access maintenance and service personnel.
Where electrical sockets or electrical isolation points are fixed below the work surface then these
points must not be able to come into contact with water. Access to electrical isolating points must
not be obstructed in case of emergency. Instruction to the owner of the appliance must be given
on how to isolate the appliance in case of emergency.
The work surface must have a minimum depth of 600mm.
The spillage tray must be fitted with the appliance
EB6 dimensional details
EB4 dimensional details
EB3 dimensional details
