EasyFoldâ„¢ Folding Seat (If Equipped)
WARNING: Ensure that the seat is unoccupied when folding it
down. Folding the seat while occupied could result in damage to
the seat or injury.
Note: The power feature is operational when the vehicle is in park and
the liftgate has been open for less than 10 minutes.
The control buttons are located on the left-hand rear quarter trim panel
(accessible from the liftgate area).
• Fold Seatback: Press and hold the control
mechanism to lower the seatback. The top portion
lowers the right (40%) seatback, and the bottom
portion lowers the left (60%) seatback..
• Unfold Seatback: Rotate the seatback upward until
the seatback latches in the upright position. The
seatback will click when it is locked into position.
LEFT
RIGHT
Seats 139
2013 MKX (mkx)
Owners Guide gf, 2nd Printing
USA (fus)
