8. The vehicle jacking points are shown here, and are depicted on the
yellow warning label on the jack.
Jack at the specified locations to avoid damage to the vehicle.
9. Small arrow-shaped marks on the sills show the location of the jacking
points.
10. Remove the lug nuts with the lug wrench.
11. Replace the flat tire with the spare tire, making sure the valve stem
is facing outward. Reinstall the lug nuts until the wheel is snug against
the hub. Do not fully tighten the lug nuts until the wheel has been
lowered.
12. Lower the wheel by turning the jack handle counterclockwise.
13. Remove the jack and fully tighten the
lug nuts in the order shown. Refer to Wheel
lug nut torque specifications later in this
chapter for the proper lug nut torque
specification.
310 Wheels and Tires
2013 MKX (mkx)
Owners Guide gf, 2nd Printing
USA (fus)
