Lincoln 2385 - Service Parts and Warranty Information; Service Parts List

Page Number - 7
Models 2385, 2386, 85650
UV INK PUMP TUBE
Form 403383
Item No. Description Qty. Part No
.
1 Bolt Connector 1 236225
2 Coupling Nut 1 237051
3 Plunger Rod 1 273293
4 Packing Nut 1 273294
5 U-cup (polyurethane) 2 *
6 Gland Nut 1 273295
7 O-ring (polyurethane) 1 *
8 Packing Washer 1 *
9 Retaining Ring 1 68908
10 Pipe Plug (1/8 nptf) 1 12511
11 Pipe Plug (1/4 nptf) 1 67359
12 Outlet Body 1 273219
13 Gasket 2 *
14 Check Seat 1 11948
15 Check Ball 1 66285
16 Spring 1 56132
17 Ball Stop 1 273218
18 Outlet Body 1 12017
19 O-ring (nitrile) 1 *
20 Pump Tube 1 242401
21 Check Ball 1 66203
22 O-ring (nitrile) 1 *
23 Foot Valve Body 1 13222
24 Retaining Pin 1 13226-9
* Included in Repair Parts Kit No. 273296
Service Parts List
