Lincoln 967 - Service Parts; Meter Components List; Battery Replacement; Battery Replacement Procedure

Page Number - 2
Form 403181
Item Description Part No. Item Description Part No
.
1 Register Module 245447 8 Trigger Assembly 68410-1
2 Chamber & Magnet Assembly 242319 9 Valve & Seat 271700
3 O-Ring 66871-12 10 Spring 69304-3
4 Housing Cap 68410-14 11 Screen 68410-2
7
5 Screw 68410-2 (2) 12 O-Ring 243176
6 Cam 68410-5 13 Adapter 243175
7 Quad Ring 68410-4 (2)
SERVICE PARTS
1
2
3
4
1
5
6
7
8
5
9
10
11
12
13
BATTERY REPLACEMENT:
Remove dial from meter, remove
4 screws from back of dial to ac-
cess battery.
Remove battery and replace with
lithium 1/2AA Battery.
After battery replacement, meter
must be reprogrammed.
©
© Indicates change
©
©
