Lincoln FlowMaster 85552 - Repair Parts List

Page Number - 11
Form 403693
FlowMaster™ Rotary Driven Electric Pump
Repair Parts List
(Common to all Models)
Repair Parts List
(Non-common items)
* Included in 270663 Soft Parts Kit.
** Used on single stage gearbox only
*** Used on 2 stage gearboxes only
Note 1 - Part is included in item 56
Item No. Qty Description All Models Item No. Qty Description All Models
1 2 Flat Head Screw 34 2 Backup Washer *
(1/4 x 1-3/4) 270635 35 2 O-Ring *
2 2 Counter Weight 272197 36 1 O-Ring 272567
3 2 Retaining Ring 270609 37 1 Pump Shaft 272548
4 1 Crankrod 270665 38 1 Ball Bearing 272556
5 2 Retaining Ring 270608 39 1 Retaining Ring 272561
6 1 Crank Eccentric 270666 40 1 Shaft Seal 272554
7 1 Ball Bearing 270607 41 1 Adapter Shaft 272546
8 1 Outlet Pin 270670 42 3 Nut - 1/4-20 51304
9 1 O-Ring (Nitrile) * 43 2 Gearbox Housing 272541
10 1 Plunger Tube 270667 44 1 O-Ring 272544
11 2 Button Head Screw 45 4 Lock Washer 272566
(1/4 x 1/2) 252877 46 4 Screw 272564
11L 2 Lockwasher 66170 47 1 Gear Set See Chart Below
12 2 Wrist Pin Bushing 270668 48 4 Screw 272574
13 1 Wrist Pin Anchor 270669 49 1 Motor Coupler 272709**
14 1 Backup Washer * 50 1 Motor 272545
15 1 Cup Seal 51 3 Screw 272568
(Polyurethane) * 52 1 Bronze Bearing 270674
16 1 Plunger Link Rod See Chart Below 53 1 O-Ring (Polyrethane) *
17 1 Spring 270616 54 1 Backup Washer *
18 1 Ball 66010 55 1 O-Ring (Nitrile) *
19 1 Pump Plunger 270671 56 1 Housing Tube See Chart Below
20 1 Reciprocating Tube See Chart Below 57 1 Bronze Bushing Note 1
21 1 Cup Seal 58 1 Shovel Plug 270707
(Polyurethane) * 59 1 Retaining Ring 270705
22 1 O-Ring 60 1 Ball Bearing 272555
(Polyurethane) * 61 1 Retaining Ring 272562
23 1 Pump Cylinder 270672 62 1 Retaining Ring 272563
24 1 Ball Cage 270675 63 1 O-Ring 272559
25 1 Ball 66001 64 1 Bearing Cover 272549
26 1 O-Ring (Nitrile) * 65 4 Lock Washer 66051
27 1 Check Seat 270664 66 4 Screws 272557
28 6 Self-Threading 67 4 Screws 272552***
Screw (8 x 1/2) 270633 68 1 Gearset See Chart Below
29 6 Gaskets (Screw) 252986 69 1 Gearset Spacer 272547***
30 1 Housing Cover 270629 70 Not Used
31 1 Cover Gasket 71 1 Woodruff Key 272560
(Nitrile) * 72 3 Lock Washers 272569
32 1 Outlet, Pin-Nut 270619 73 1 Pump Housing 272540
33 4 O-Ring * Soft parts Kit 270663
Item Qty. Description Model Model Model Model Model Model Model Model Model Model Model
No. 85552 85553 85554 85566 85567 85568 85569 85587 85591 274873© 275626©
16 1 Plunger Link Rod 270641 270648 270648 270698 270614 270648 270641 270641 270645 270641 270719
20 1 Reciprocating Tube 270642 270649 270649 270649 270617 270649 270642 270642 270646 270642 270642
56 1 Housing Tube 270643 270650 270650 270650 270628 270650 270643 270662 270647 270643 270643
47 1 Gear Set (Final Stage) 272584 272584 272663 272663 272663 272663 272542 272663 272663 272584 272584
68 1 Gear Set (First Stage) 272585 272585 272543 272543 --- --- 272543 272543 --- --- 272573
74 1 Safety Unloader 272722 272722 --- 272722 272722 272722 272572 272722 272722 274833 272722
© Indicates change
