Page Number - 9
Form 403693
FlowMaster™ Rotary Driven Electric Pump
Illustration #11
MODEL DIM "A" in (mm) DIM "B" in (mm)
85552, 85569, 85587, 274873© 13.69 (348) 21.25 (540)
85554, 85567, 275626© 19.00 (483) 26.60 (676)
85553, 85566, 85568 27.50 (699) 35.00 (889)
85591 34.00 (864) 41.60 (1,057)
© Indicates change
