Lindab WH25 - Installations within vertical light wall (Shaft wall)

OVERVIEW
WH25
LINDAB SAFE
7/50
EI 120 S
(300 Pa)
EI 90 S
(300 Pa)
EI 60 S
(500 Pa)
EI 30 S
(500 Pa)
Flexible wall
EI 120 S Installation remote from the vertical light wall (plasterboard) p.28
Wall minimum thickness 100 mm
Wall rock wool density up to 100 kg/m³ (optional)
Plasterboard and rock wool 100 kg/m³ or mortar or plaster putty sealing
ve (i↔o)
D/W
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
EI 120 S Installation remote from the vertical light wall (plasterboard) with Fire Batt (Weichschott) sealing p.30
Wall minimum thickness 100 mm
Wall rock wool density up to 100 kg/m³ (optional)
Rock wool density 140 kg/m³ and endothermic varnish sealing
ve (i↔o)
D
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
EI 120 S Installation remote from the vertical light wall (gypsum blocks wall) p.26
Wall minimum thickness 100 mm
Wall minimum density 995 kg/m³
Mortar or plaster putty sealing
ve (i↔o)
W
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
EI 120 S Installation remote from the vertical light wall (gypsum blocks wall) with Fire Batt (Weichschott) sealing p.30
Wall minimum thickness 100 mm
Wall minimum density 995 kg/m³
Rock wool 140 kg/m³ and endothermic varnish sealing
ve (i↔o)
D
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
Floor
EI 120 S Installation remote from the oor p.32
Floor minimum thickness 150 mm
Floor minimum density 650 kg/m³
Mortar or plaster putty sealing
ho (i↔o)
W
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
EI 90 S Installation remote from the oor p.32
Floor minimum thickness 100 mm
Floor minimum density 650 kg/m³
Mortar or plaster putty sealing
ho (i↔o)
W -
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
 Installations within vertical light wall (Shaft wall)
EI 90 S
(300 Pa)
EI 60 S
(300 Pa)
EI 30 S
(300 Pa)
Flexible
wall
EI 90 S Installation within vertical light wall (Shaft wall) p.34
Wall minimum thickness 90 mm
Plasterboard and mortar or plaster putty sealing
ve (i↔o)
W
Ø
min 100
max 315
Ø
min 100
max 315
Ø
min 100
max 315
WH25
7/50
LINDAB SAFE
