Service Training
Section 6
Page 50
3) LIFTING CUT-OFF
To protect the battery from too high discharge, set the residual capacity value (in %) at which the hoist cut
is produced: 20(*) - 25 - 30 - 35 - 40%.
- (*) Standard control for an open lead battery.
- Setting recommended for a leak proof battery (gel): 30%
TIPS TO ADJUST THE HOIST CUT
After checking the real status of the battery on the cut, gravity and voltage on an open lead battery, voltage
on a gel battery, it is possible to fine-tune the setting according to real use of the battery:
- If the indicator cuts too early, reduce the residual capacity value (E.g.: 25% to 20%)
- If the indicator cuts too late, increase the residual capacity value (E.g.: 25% to 30%)
Remarks: - Minimum gravity, battery 80% discharged; 1,14
- Maximum gravity, battery 100% charged; 1.29 to 1.32 according to models.
4) RESET TIME
After cutting the discharge indicator, it can be reset only after a period of:
0(*) - 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 minutes.
(*): standard setting
MENU 5-1: Programming initialisation
Same as menu 1
Menu 5-2: Initialisation of an hour meter after replacement
On a new multifunction indicator, it is possible to program the hour meter from the old one.
NOTE:
The hour meter can be reinitialised only if there are less 2.9 hours.
Menu 5-3: Service Point Address
This menu shows the Service Point address closest to the truck user:
- Company
- Telephone No.
- Name of person to contact
Menu 5-4: Setting the date
Example: 011102 means 01.11.02
Menu 5-5: Setting of time
Example: 161202 means 16 hours 12 minutes and 2 seconds
(*) By default
