Linde T20 SP - Page 23

Service Training
Section 2
Page 7
Note:
To remove the reduction gear, it is recommended to first
remove the drive unit (see section 2.1.1 Removal/instal-
lation of motor unit)
On clearing the chassis, the motor unit can be
manipulated more easily:
- Drain the reduction gear (4)
- Remove the steering motor reducer (1)
- Remove the traction motor (2)
- Pull out the support plate (8)
CAUTION
The traction motor and the reduction gear are
heavy. Use handling gloves to disengage the
motor and the reduction gear from the chassis.
To reinstall the reduction gear, proceed in the reverse
order as for removal.
Note:
In the chassis, the position of the drive wheel is at the
left and the reduction gear is at the right.
- Fill the reduction gear with the stipulated oil quality (SAE
80 W 90, API, GL5, MIL.L 21DSC quantity 1.5 l ).
CAUTION
Following this operation, it is absolutely
necessary to check the electric steering
control.
(see section 4.5: steering motor reducer).
