Linear HSLG Series User Manual

HSLG Slide Gate Operator Installation Guide - 27 - P1220 X14
Error Indications
During abnormal operation, the Controller’s displays and beeper will
indicate the error condition that has occurred.
Entrapment
If an entrapment condition occurs detected by two repeated open or
close obstruction triggers, the Controller will lock the operator out. The
beeper will sound constantly and the gate will not operate. To reset the
Controller press the STOP button or press the RESET button on the
operator’s cover.
COMM LINK Connection Failure
In dual gate installations, if there is a connection failure between the
two operators, the COMM LINK indicator will blink once a second.
During this condition the gate will not operate, except if triggered by the
FIRE DEPT input, which functions normally.
MGT Obstacle Transmitter Trouble
If any MGT transmitters are used with the operator, their supervision
feature will alert the Controller if there is any trouble with the transmitter.
MGT transmitters send hourly status reports and will send low battery
reports when the transmitter has a low battery. The MGT transmitters
also have a tamper detection switch that will trigger when their case
is opened.
When the Controller detects a low transmitter battery, a tamper signal,
or missing transmitter status reports, the gate will still operate normally,
but the beeper will change as follows:
• The Pre-start Alarm will beep twice as fast.
• The Run Alarm will beep twice as fast and continue for ve minutes
after the gate stops.
• The sounder will “chirp” every ve seconds when the gate is idle.
Correct the trouble (close case, replace battery, or replace transmitter)
to clear the obstacle transmitter trouble indications.
Maximum Run Time Exceeded
If the Maximum Run Time is exceeded, the Controller stops the operator
the same as if a double obstacle has occurred in an entrapment
condition. The entrapment alarm sounds constantly, and is cleared by
pressing the STOP button or the RESET button on the cover. After the
STOP or RESET button is pressed, because the Maximum Run Time has
been exceeded, the sounder will beep twice every ve seconds. The
next operation of the gate will clear the indication.
CONTROLLER ERROR CAUSES AND INDICATIONS
ERROR CAUSE ERROR INDICATION HOW TO CLEAR
TWO SAFETY REVERSALS
(ON SINGLE GATE OR ON
EITHER DUAL GATE)
En 00, CONTINUOUS
ALARM BEEPER, GATE
DISABLED
PRESS STOP BUTTON
MAXIMUM RUN TIMER
EXCEEDED ON OPENING
En 01, AND MAX RUN
LED, CONTINUOUS ALARM
BEEPER, GATE DISABLED
PRESS STOP BUTTON,
CLEARS CONTINUOUS
ALARM, THEN DOUBLE
BEEP EVERY 5 SECONDS
UNTIL NEXT OPERATION
MAXIMUM RUN TIMER
EXCEEDED ON CLOSING
En 02, AND MAX RUN
LED, CONTINUOUS ALARM
BEEPER, GATE DISABLED
PRESS STOP BUTTON,
CLEARS CONTINUOUS
ALARM, THEN DOUBLE
BEEP EVERY 5 SECONDS
UNTIL NEXT OPERATION
COMM LINK FAILURE
En 03, AND COMM LINK
LED, CONTINUOUS ALARM
BEEPER FOR 1 MINUTE,
GATE DISABLED (EXCEPT
FOR FIRE DEPT INPUT)
PRESS STOP BUTTON,
CLEARS CONTINUOUS
ALARM
GATE FULL OPEN
RESULTING FROM FIRE
DEPT INPUT
En 04, GATE DISABLED PRESS STOP BUTTON
FAIL SAFE OR FAIL SECURE
BECAUSE OF BATTERY
VOLTAGE DROP BELOW
21.6 VDC DUE TO AC
POWER LOSS
En 05, GATE DISABLED
BATTERY VOLTAGE MUST
RISE ABOVE 24 VDC
OTHER CONTROLLER IN
ENTRAPMENT (DUAL GATE)
En 06, GATE DISABLED
CLEAR ENTRAPMENT
ON OTHER CONTROLLER
(PRESS STOP)
LOW AC VOLTAGE AT
CONTROLLER
En 07, GATE DISABLED
RESTORE AC POWER TO
NORMAL LEVEL
INPUT TRIGGERED DURING
ENTRAPMENT LOCKOUT
En 08, GATE DISABLED PRESS STOP BUTTON
COMPATIBILITY PROBLEM En 09, GATE DISABLED
UPDATE FIRMWARE AND
RESET BOTH PAIRED
CONTROLLERS
EEPROM PROBLEM En 10, GATE DISABLED
TRY RESET, CALL TECH.
SUPPORT
DC MOTOR MISMATCH En 11, GATE DISABLED
REPROGRAM MOTOR TYPE
OR CHANGE DC MOTOR
BOARD, NEXT GATE
MOVEMENT WILL RETRY
DC MOTOR CHECK
MOTOR FAILURE En 12, GATE DISABLED REPLACE MOTOR
AC POWER LOSS IN OPEN
OR CLOSE IMMEDIATE
POWER FAIL MODE
En 13 REAPPLY AC POWER
MAXIMUM RUN TIMER
EXCEEDED AFTER AC
POWER LOSS
En 14
BATTERY VOLTAGE MUST
RISE ABOVE 24 VOLTS
MGT SUPERVISORY
CONDITION (TAMPER, LOW
BATTERY, MISSING HOURLY
STATUS)
FAST BEEPS DURING
PRESTART, FAST BEEP RUN
ALARM, CHIRP EVERY 5
SECONDS AT IDLE
CLEARS WHEN MGT
CONDITION CLEARS
WARNING
The Stop and/or Reset button must be located in the line-
of-sight of the gate. Activation of the reset control shall not
cause the operator to start.
