Linear LDCO850 User Manual

9
SETTING UP THE WALL STATION
This Wall Station allows operation of the light and door using the buttons, but it does much more when paired
with our Android or iOS application. It can operate your garage door, control lights and inform you of people
coming and going, all while you are on the go.
Requirements
To use the Wall Station with the app you will need:
• a Wi-Fi network with internet connectivity,
• a strong Wi-Fi signal in the garage where you are installing the Wall Station and
• an Android or iOS phone.
The Wall Station has two LEDs that convey information at a
glance.
LEDs on the Wall Station
Vacation Mode LED
ON Normal operation
FLASHING Vacation mode enabled
Wi-Fi Connectivity LED
RED Not connected to access point
YELLOW Performing update
GREEN Connected to access point
The top LED provides information on the vacation mode.
The bottom LED indicates the state of the Wi-Fi connection
and device.
Test Wi-Fi Signal Strength with Your Smart Phone
It is paramount that the Wall Station receives strong signal from your home’s Wi-Fi router.
If you have 2 or 3 bars on your phone from the Wi-Fi network, the signal is strong and you can proceed. If not,
use one of these options to extend your Wi-Fi network’s range.
• Move your Wi-Fi router closer to the garage.
• Purchase a Wi-Fi range extender.
Strong Wi-Fi signal
Wall Station will connect
to your Wi-Fi network.
Weak Wi-Fi signal
Wall Station may not connect
to your Wi-Fi network.
No Wi-Fi signal
Wall Station will not connect
to your Wi-Fi network.
