CHAPTER 3B ENGINE 50cc/80cc ATV SERVICE MANUAL09.0
CHAPTER 3B ENGINE PAGE 3B - 66 -
Clean assembly with solvent and lube with dry
graphite or light grease.
Do not use heavy grease. This will limit the fast
movement of the starter pinion.
INSTALLATION
Apply a light film of grease to the gears and install
the starter pinion by reversing the removal
procedure.
Install the left crankcase cover.
3.10 Magneto
3.10.1 Dismantling:
Remove the four screws, and remove the fan
cover.
