7
RS232 Operation
RS232 ports can be used for bi-directional RS232 signal pass-through
between the transmitter and receiver.
HDBT
Receiver
Transmitter
RS232 cable
RS232 Device
RS232 cable
RS232 Device
RX
TX
GND
TX
RX
G
RS232 Port Connected RS232 Device Pins
