Link EXT40-4K - Specifications

3
Specifications
Technical
Input/Output Signal Type HDMI with 4K@60Hz 4:2:0, HDCP 2.2
Input/Output Resolution
Supported
Up to 4096x2160@60Hz, including
4K@60Hz/4K@30Hz/1080P/1080i/720P
Note: 4096x2160/3840x2160@50/60Hz is
based on chroma sub-sampling 4:2:0 8-bit only.
Deep color
4K: 8/10/12 bit
1080P: up to 16 bit
Maximum Data Rate 10.2 Gbps
Maximum Pixel Clock 340MHz
Audio Format Supported
Supports multichannel audio up to PCM 7.1,
Dolby True HD, DTS HD Master Audio, Dolby
Atmos and DTS:X
General
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Humidity 10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Power Supply DC 18V 1A
Power Consumption
(Maximum)
8.88W (Pair, PoC)
Device Dimension
(W x H x D)
108.8mm x 15mm x 64.2mm/
4.3" x 0.6’’ x 2.5’’ each for TX/RX
Product Weight 0.18kg/0.4lb each for TX/RX
