Linksys easyHOTSPOT WRT54GL User Manual

Page 9
3. Range Extenders
For a simple one room Cafe-style installation, a single easyHotspot unit will be
all that is needed.
For larger coverage areas (e.g. Motels/Hotels), the coverage range will need
to be expanded using some combination of booster antennas, amplifiers, and
Range Extenders. As each installation will be unique, it is not possible to
cover all possible scenarios here, but the basic design will probably be
something like one of the options shown below.
Range Extension Options
Internet
Internet
Range
Extender
Unit
WDS
WDS
WDS or
BRIDGE
AP
It is not possible to cover the details of all possible range extension options
here. But it will generally be true that the range extender units will be setup in
BRIDGE, AP, or WDS (=AP+BRIDGE) modes.

Linksys easyHOTSPOT WRT54GL Specifications

General

Model	WRT54GL
Category	Wireless Router
Frequency Band	2.4 GHz
Wireless Standards	802.11b, 802.11g
Ports	4 x 10/100 Ethernet LAN, 1 x 10/100 Ethernet WAN
Security	WEP, WPA, WPA2
Standards	IEEE 802.3, IEEE 802.3u
Buttons	Reset
LEDs	Power, Internet
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-4°F to 158°F (-20°C to 70°C)
Operating Humidity	10% to 85% non-condensing
Storage Humidity	5 to 90% Non-condensing
