Linksys EtherFast
®
II Series
ARP Table Settings 49
Adding Static ARP Table Entries 49
Deleting Static ARP Table Entries 51
Searching for ARP Table Entries 51
Routing Table 52
Adding Router Table Entries 53
Deleting Router Table Entries 54
Searching for Router Tsble Entries 55
DHCP Gateway Settings 55
Ping Settings 59
Bridging 61
Static Filtering 62
Spanning Tree Functions 63
Spanning Tree Port Configuration 63
Spanning Tree Port States 65
Spanning Tree Path Costs 67
Spanning Tree Port Priorities 68
SNMP Functions 69
Stacking 72
Other Protocols 76
Port Trunking 77
Port Mirroring 79
Setting Quality of Service Parameters 81
SNMP and RMON Management 108
Overview 108
SNMP Agent and MIB-2 (RFC 1213) 108
RMON MIB (RFC 1757) and Bridge MIB (RFC 1493) 109
RMON Groups Supported 109
Bridge Group s Supported 110
Appendix 111
About Fast Ethernet 111
About Gigabit Ethernet 112
Fiber Optic Cabling 112
Twisted-Pair Cabling 113
Crimping Your Own Network Cables 114
Specifications 115
Customer Support 116
2224 Layer 2 Management 24-Port 10/100 Ethernet Switch
n
nect II 2224
Introduction
Maximize your network potential with this high-speed, high-reliability, man-
ageable and stackable switch. The ProConnect® II 2224 Ethernet Switch
from Linksys delivers a combination of wire-speed Ethernet, Fast Ethernet,
and Gigabit solutions, all in one surprisingly affordable package. Perfect for
demanding enterprise environments, this switch's intelligent design and built-
in SNMP provide maximum network control, regulating traffic and eliminat-
ing server bottlenecks. Its web browser-based management interface and
upgrade capability makes it ideal for busy network administrators. The
ProConnect II 2224 is rack mountable and includes two Expansion Slots that
accept optional Gigabit Modules (fiber or copper) to let you grow your net-
work as your needs grow. Three Port Trunking groups eliminate bottlenecks,
and you can stack up to 8 switches and manage them as one. So when you're
ready to bring your network up to speed, get Linksys reliability, manageabili-
ty, stackability, and expandability -- with the ProConnect® II 2224 Ethernet
Switch.
• 24 10/100 auto-MDI/MDI-X ports and 2 Gigabit Expansion Slots - speeds
up to 1000Mbps
• Optimizes your network traffic with 802.1q VLAN support and 802.1p
traffic prioritization
• Stacking support for up to 8 switches lets your network grow
• Manageable via Console, Telnet, web browser, and SNMP/RMON
• 256K Packet Buffer and 32K MAC address entries
• IEEE 802.1Q VLAN support for up to 128 groups
• IGMP Multicast Filtering and Snooping
• Supports 3 Port Trunking groups that include up to 4 10/100 ports and up
to 2 ports for the Gigabit modules
• IEEE 802.1d Spanning Tree support for redundant connections
