Linn KELTIK - ADJUST RESISTOR VALUES; TREBLE AND BASS ADJUSTMENT TABLES

14
Treble adjustment
Resistor value Adjustment level (dB)
680 ohm + 6.0
750 ohm + 5.5
820 ohm + 5.0
1 Kohm + 4.5
1.1 Kohm + 4.0
1.3 Kohm + 3.5
1.6 Kohm + 3.0
2 Kohm + 2.5
2.7 Kohm + 2.0
3.6 Kohm + 1.5
6.2 Kohm + 1.0
15 Kohm + 0.5
No resistor 0
Treble Factory Setting: - 3dB (no resistor)
Bass adjustment
Resistor value Adjustment level (dB)
68 ohm + 6
82 ohm + 5
91 ohm + 4
120 ohm + 3
150 ohm + 2
180 ohm + 1
220ohm 0
270 ohm - 1
360 ohm - 2
560 ohm - 3
910 ohm - 4
2.2 Kohm - 5
No resistor - 6
Bass Factory Setting: 0dB (220ohm resistor)
WARNING
For use by Linn Dealers only
ADJUST RESISTOR VALUES
