Note – Invert the phase between the power amplifiers and the speakers
INTERCONNECTIONS
PRE-AMP
KELTIK AKTIV
POWER AMP
POWER AMP
POWER AMP
RIGHT KELTIK LOUDSPEAKER LEFT KELTIK LOUDSPEAKER
TREBLE
MIDRANGE
BASS
