Lippert Components ELECTRIC SLIDEOUT SYSTEM - WIRING DIAGRAM; System Electrical Connections Diagram

Fig.9
19
BATTERY
MOTOR
RED
CHANGE OF POLARITY
REVERSES MOTOR
GREEN MOTOR
30A AUTO RESET BREAKER
LOCATE WITHIN 18” OF BATTERY
SWITCH
BATTERY (-) WHITE
BATTERY (+) BLACK
BATTERY (-) WHITE
OUT
- +
RED MOTOR
BLACK
BATTERY ( -)
BATTERY (+)
CAUTION!
HIGH VOLTAGE
IN
Fig. 10
WIRING DIAGRAM
AUTO RESET BREAKER
SUPPLIED BY CUSTOMER
10 GAUGE WIRE MINIMUM
