Rev: 11.09.20 Page 2 CCD-0001450
Introduction
The OneControl® Touch Panel (OCTP) (formerly MyRV®) is a compatible touchscreen device that provides
system controls and monitoring software for the recreational vehicle unit. The systems include slide-outs,
leveling systems, awnings, lighting, temperature, water tanks, tire pressure, battery levels and any other
compatible systems installed on the unit and programmed into the OneControl system. Powering up the
unit will also power the OneControl Touch Panel and the various controllers throughout the unit.
Compatability
This thermostat control is compatible with the following appliances:
1. Single-stage LP gas furnaces with self-contained fan control.
2. Conventional air conditioning systems with one or two-speed fans.
3. Combination air conditioning/heat pump systems with one or two-speed fans.
TABLE OF CONTENTS
Introduction 2
Compatability 2
Specications 3
Safety 3
Resources Required 3
Preparation 4
Prior to Installation 4
Connections 4
Installation 4
Controller 4
Harness Connections 6
Zone Sensor Installation 7
Operation 8
Power On/O 8
Touch Panel 8
Adjusting HVAC Control 9
Wiring Diagram 11
Notes 13
Specifications Min Typ Max Units
Operating Supply Voltage 9 13.8 18 Volts DC
Operating Temperature Range -10 (14) N/A +45 (113) C (F)
Quiescent Current N/A 30 45 mA DC
Sink Current (Generator) N/A 1.2 2.0 A DC
Focused Relay Drive Current N/A N/A 1.5 A DC
