Quick Drop Stabilizer
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004455
6. Drill a 3/16" pilot hole in the Fig. 22A position.
7. Install ¼” self-drilling screw through the mounting hole
into the cross member (Fig. 22A).
8. Repeat process if additional Quick Drop Stabilizer legs
are being installed.
NOTE: Figure 23 shows mounting location with more clarity.
Fig.22
Mounting Brackets
Quick Drop Stabilizers
Cross Member
Center Mounting Hole
Frame
Fig.23
A
