Quick Drop Stabilizer
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004455
NOTE: The Quick Drop stabilizer can be completely
retracted. However, it is recommended to stop and pull
the spring latch (Fig. 39A) and completely retract the Quick
Drop leg (Fig. 39B) into the inner arm for the next use. Finish
turning the hex coupler counterclockwise to completely
retract the Quick Drop Stabilizer.
DO NOT OVER TIGHTEN THE HEX COUPLER WHILE
RETRACTING THE QUICK DROP STABILIZER.
2. Loop the spring hook (Fig. 40A) into one of the four holes
on the footpad (Fig. 40B).
3. Repeat process for other stabilizer legs.
NOTE: Make sure the stabilizer legs are fully retracted
before moving the trailer.
A
Fig.39
Fig.40
A
B
B
