Lippert Insight Back-up
Camera LCD Display Kit
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0004028
Introduction
The Lippert Insight Back-up Camera LCD Display Kit is a
7” camera display, mounting arm and USB power cord that
streams wireless video from your Lippert back-up camera.
Additional information about this product can be obtained
from lci1.com/support or by using the myLCI app.
Replacement kits can be ordered from https://store.lci1.
com/electronics or by using the myLCI app.
The myLCI app is available for free on Apple App Store
®
for iPhone
®
and iPad
®
and also on Google Play
™
for
Android
™
users.
Apple App Store
®
, iPhone
®
, and iPad
®
are registered
trademarks of Apple Inc.
Google Play
™
and Android
™
are trademarks of Google Inc.
Safety
Read and understand all instructions before installing or
operating this product. Adhere to all safety labels. This
manual provides general instructions. Many variables can
change the circumstances of the instructions, i.e., the
degree of difficulty, operation and ability of the individual
performing the instructions. This manual cannot begin
to plot out instructions for every possibility, but provides
the general instructions, as necessary, for effectively
interfacing with the device, product or system. Failure
to correctly follow the provided instructions may result
in death, serious personal injury, severe product and/or
property damage, including voiding of the Lippert limited
warranty.
Parts List
Resources Required
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
• Ladder
Lippert Insight LCD Display KitLippert Insight LCD Display Kit——20201128482020112848
LetterLetter Part NumberPart Number DescriptionDescription QtyQty
A N/A 7” Display 1
B N/A USB Cord 1
C N/A Mounting arm 1
A
B
C
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT A
PROCEDURE HAS A SAFETY RISK INVOLVED AND
MAY CAUSE PERSONAL INJURY, PRODUCT AND/OR
PROPERTY DAMAGE IF NOT PERFORMED SAFELY
AND WITHIN THE PARAMETERS SET FORTH IN THIS
MANUAL.
MOVING PARTS CAN PINCH, CUT, AND CRUSH.
KEEP HANDS OFF MOVING PARTS AT ALL TIMES
AND EXERCISE CAUTION WHEN EXTENDING OR
RETRACTING THE LADDER.
To Next Page
